| 266 nm Single-Frequency Frequency-Doubled Laser | ||||
|---|---|---|---|---|
| Technical Parameter | Unit | Technical Specifications | ||
| Minimum | Typical | Maximum | ||
| Central Wavelength | nm | — | 266 (Customizable) | — |
| Optical Mode | / | Single Longitudinal Mode, Continuous Wave | ||
| Output Power | mW | 5 | 10 | 15 |
| Linewidth | kHz | 5 | 10 | 25 |
| Output Power Stability (RMS) @ 3h | % | 1 | 1 | 1 |
| Output Power Adjustment | % | 10 – 100 | ||
| Wavelength Tuning Range | pm | 50 | 100 | 150 |
| Polarization Extinction Ratio | dB | 18 | 20 | 23 |
| Beam Quality | / | M² < 1.3 | ||
| Operating Voltage | VAC | 90–250V (50–60Hz) | ||
| Operating Temperature | °C | 15 | 25 | 35 |
| Output Type | / | Free-Space Optical Output | ||
| Output Beam Diameter | mm | 0.8 | 1 | 1.2 |
| Beam Waist Position (Relative to Output Port) | m | < 1 | ||
| Dimensions | mm | 290 (L) × 500 (W) × 130 (H) | ||
The 266 nm frequency-converted laser is a high-performance narrow-linewidth frequency-multiplied laser developed by combining the company’s proprietary narrow-linewidth fiber laser with efficient and stable frequency conversion technology. It offers excellent beam quality and high power stability, and can be applied in fields such as semiconductor processing and material analysis.
Product Features
Narrow Linewidth Preservation Technology
Fourth-Harmonic Generation Technology Breakthrough
Deep Ultraviolet Optical Processing
Typical Applications
Semiconductor Processing
Material Analysis
