| Technical Parameter | Unit | Technical Specification | ||
|---|---|---|---|---|
| Min | Typical | Max | ||
| Wavelength Range | nm | 1530 | 1550 | 1560 |
| Laser Mode | / | Single Longitudinal Mode, Continuous Wave | ||
| Output Power | mW | 50 | ||
| Linewidth | kHz | ≤0.1 | ||
| Optical Signal-to-Noise Ratio | dB | ≥50 | ||
| Frequency Noise | Hz²/Hz @10Hz | <5000 | ||
| Hz²/Hz @100Hz | <1000 | |||
| Hz²/Hz @1kHz | <100 | |||
| Hz²/Hz @10kHz | <15 | |||
| Output Power Stability (P-P) | % | ≤0.5 | ||
| Output Power Adjustment | % | 1–100 | ||
| Wavelength Thermal Tuning Range | nm | ±0.2 (Customizable) | ||
| Polarization Type | / | Linear Polarization | ||
| Polarization Extinction Ratio | dB | >20 | ||
| Beam Quality | M² | M² < 1.05 | ||
| Operating Voltage | VDC | 5 | ||
| Operating Temperature | °C | −10 | 45 | |
| Power Consumption | W | <15 | ||
| Storage Temperature | °C | −40 | 70 | |
| Output Fiber Type | / | PM1550 | ||
| Output Fiber Length | m | >0.8, Customizable | ||
| Output Fiber Connector | / | FC/APC | ||
| Dimensions | mm | 175 (L) × 140 (W) × 25 (H) | ||
The 1.5 μm hundred-hertz ultra-narrow linewidth fiber laser is a laser with completely independent intellectual property rights and performance reaching an internationally advanced level. It adopts a special resonant cavity structure design and combines noise suppression and linewidth-narrowing technologies to achieve ultra-narrow linewidth laser output as low as the hundred-hertz level.
Product Features
Ultra-Narrow Linewidth
Low Intensity Noise
High Environmental Adaptability
Typical Applications
High-Precision Fiber Sensing
Quantum Computing
Quantum Precision Measurement
