| Technical Parameter | Unit | Technical Specification | ||
|---|---|---|---|---|
| Min | Typical | Max | ||
| Wavelength Range | nm | 1530 | 1550 | 1560 |
| Output Mode | / | Single-mode, Continuous Wave | ||
| Output Power | mW | 25 | ||
| Spectral Width | nm | 0.04 | ||
| Optical Signal-to-Noise Ratio | dB | > 50 | ||
| Output Power Stability (P-P) | % | ≤ 0.5 | ||
| Output Power Adjustment | % | 1 – 100 | ||
| Wavelength Tuning Range | nm | ±0.2, Customizable | ||
| Operating Voltage | VDC | 5 | ||
| Operating Temperature | °C | -10 | 45 | |
| Storage Temperature | °C | -40 | 70 | |
| Output Fiber Type | / | PM1550 | ||
| Output Fiber Length | m | > 0.8, Customizable | ||
| Output Fiber Connector | / | FC/APC | ||
| Dimensions | mm | 175 (L) × 140 (W) × 25 (H) | ||
The 1.5 μm point light source is a miniaturized laser device centered on the infrared band (eye-safe wavelength) with excellent optical performance. With eye safety, high peak power, miniaturized packaging, and environmental stability as its core advantages, it serves as an ideal light source for fields such as LiDAR, quantum technology, and precision medical applications.
Product Features
High Beam Quality
Stable Power
Polarization-Maintaining Single-Mode Output
Typical Applications
Scientific Research
Experimental Teaching
Device Testing and Measurement
Precision Measurement and Imaging
