| Technical Parameter | Unit | Technical Specification | ||
|---|---|---|---|---|
| Min | Typical | Max | ||
| Wavelength Range | nm | 1530–1560 | ||
| Output Power | mW | 50 | ||
| Bandwidth | GHz | 0.1 – 40 | ||
| Optical Signal-to-Noise Ratio | dB | ≥ 50 | ||
| Output Power Stability (P-P) | % | ≤ 0.5 | ||
| Output Power Adjustment | % | 1 – 100 | ||
| Wavelength Tuning Range | nm | ±0.2, Customizable | ||
| Polarization Type | / | Linear Polarization | ||
| Polarization Extinction Ratio | dB | > 20 | ||
| Operating Temperature | °C | −10 | 45 | |
| Storage Temperature | °C | −40 | 70 | |
| Output Fiber Type | / | PM1550 | ||
| Output Fiber Length | m | > 0.8, Customizable | ||
| Output Fiber Connector | / | FC/APC | ||
| Dimensions | mm | 175 (L) × 140 (W) × 25 (H) | ||
The core advantage of the 1.5 μm laser phase-modulated fiber seed source lies in its adjustable phase. Combined with ultra-low phase noise, high power stability, and an all-polarization-maintaining, interference-resistant design, it makes an ideal light source for cutting-edge fields such as quantum technology and precision sensing.
Product Features
Low Phase Noise
High Power Stability
All-Polarization-Maintaining Optical Path
Adjustable Phase
Typical Applications
Optical Quantum Communication
Distributed Acoustic Sensing (DAS)
LiDAR
Femtosecond Micromachining
