| Technical Parameter | Unit | Technical Specification | ||
|---|---|---|---|---|
| Min | Typical | Max | ||
| Wavelength Range | nm | 980–1120 | ||
| Laser Mode | / | Single Longitudinal Mode, Continuous Wave | ||
| Output Power | mW | 20 | ||
| Spectral Width | GHz | 100 | ||
| OSNR | dB | 50 | ||
| Output Power Stability | % | RMS < 0.2 / P-P < 1 | ||
| Polarization Type | / | Linear Polarization | ||
| Polarization Extinction Ratio | dB | 20 | ||
| Beam Quality | / | M² < 1.05 | ||
| Operating Voltage | VDC | 24 or Other | ||
| Power Consumption | W | 20 | ||
| Operating Temperature | °C | −10 | 45 | |
| Storage Temperature | °C | −40 | 70 | |
| Output Fiber Type | / | PM980 | ||
| Output Fiber Length | m | 0.6 | ||
| Output Fiber Connector | / | FC/APC, Optional | ||
| Dimensions | mm | 240 (L) × 204.5 (W) × 31 (H) | ||
The 1.0 μm point light source is a single-mode continuous-output fiber laser. It features a Fabry–Perot cavity design and employs single-clad fiber pumping technology to achieve high-performance laser output, with an output power of up to 200 mW. It also offers nearly diffraction-limited beam quality and can be widely used in scientific research, experimental teaching, and device testing and measurement.
Product Features
High Beam Quality
Stable Power
Polarization-Maintaining Single-Mode Output
Typical Applications
Scientific Research
Experimental Teaching
Device Testing and Measurement
