1.0 μm High-Reliability Single-Frequency Seed Laser
1.0 μm High-Reliability Single-Frequency Seed Laser

1.0 μm High-Reliability Single-Frequency Seed Laser

The 1.0 μm single-frequency seed laser is a laser with fully independent intellectual property rights and performance at an internationally advanced level. It features an ultra-compact DBR short-cavity design, effectively eliminating mode hopping and achieving ultra-narrow linewidth single longitudinal mode output.

The core technology is highly doped specialty fiber, which forms a centimeter-scale single-frequency laser resonator, enabling kilohertz-level spectral linewidth output and preventing mode hopping. Optimized circuit design ensures high frequency stability and low intensity noise. Additionally, the resonator incorporates special temperature-control protection and anti-shock vibration design, ensuring stable operation even under harsh environmental conditions.

Product Features

  • Ultra-Narrow Linewidth

  • Mode-Hop Free

  • No Sudden Noise Spikes

  • High Side-Mode Suppression Ratio (SMSR)

  • Low Relative Intensity Noise (RIN)

  • Excellent Shock Resistance and High/Low Temperature Performance

Typical Applications

  • Gravitational Wave Detection

  • Fiber Sensing

  • LiDAR

  • Coherent Communication

Category:
Inquiry Now
Technical ParameterUnitSpecification
MinTypicalMax
Central Wavelengthnm1083.2
Laser Mode/Single Longitudinal Mode, Continuous Wave
Output PowermW100
LinewidthkHz<50
Optical Signal-to-Noise RatiodB>50
Output Power Stability (P-P)%≤0.5
Wavelength Thermal Tuning Rangenm0.2
Polarization Extinction RatiodB23
Operating VoltageVDC5
Operating Temperature℃-2050
Storage Temperature℃-4080
Output Fiber Type/PM980
Output Fiber Lengthm0.6
Output Fiber Connector/FC/APC
Dimensionsmm205 (L) × 150 (W) × 28 (H)

The 1.0 μm single-frequency seed laser is a laser with fully independent intellectual property rights and performance at an internationally advanced level. It features an ultra-compact DBR short-cavity design, effectively eliminating mode hopping and achieving ultra-narrow linewidth single longitudinal mode output.

The core technology is highly doped specialty fiber, which forms a centimeter-scale single-frequency laser resonator, enabling kilohertz-level spectral linewidth output and preventing mode hopping. Optimized circuit design ensures high frequency stability and low intensity noise. Additionally, the resonator incorporates special temperature-control protection and anti-shock vibration design, ensuring stable operation even under harsh environmental conditions.
